AC Switching Characteriscs
Data Sheet
© 2024 Microchip Technology Inc. and its subsidiaries
DS00003831E - 51
...........continued
V
DD
= 1.0V
–STD
V
DD
= 1.0V
–1
V
DD
= 1.05V
–STD
V
DD
= 1.05V
–1
Unit Condition
309 428 309 428 MHz Two-port, all supported widths, non-pipelined, simple-write, and
write-feed-through
343 428 343 428 MHz Dual-port, all supported widths, pipelined, simple-write, and write-
feed-through
309 428 309 428 MHz Dual-port, all supported widths, non-pipelined, simple-write, and
write-feed-through
343 428 343 428 MHz Two-port pipelined ECC mode, pipelined, simple-write, and write-
feed-through
279 295 279 295 MHz Two-port non-pipelined ECC mode, pipelined, simple-write, and write-
feed-through
343 428 343 428 MHz Two-port pipelined ECC mode, non-pipelined, simple-write, and write-
feed-through
196 285 240 285 MHz Two-port non-pipelined ECC mode, non-pipelined, simple-write, and
write-feed-through
240 285 240 285 MHz Two-port, all supported widths, pipelined, and read-before-write
240 285 240 285 MHz Two-port, all supported widths, non-pipelined, and read-before-write
240 285 240 285 MHz Dual-port, all supported widths, pipelined, and read-before-write
240 285 240 285 MHz Dual-port, all supported widths, non-pipelined, and read-before-write
240 285 240 285 MHz Two-port pipelined ECC mode, pipelined, and read-before-write
198 240 198 240 MHz Two-port non-pipelined ECC mode, pipelined, and read-before-write
240 285 240 285 MHz Two-port pipelined ECC mode, non-pipelined, and read-before-write
193 240 193 240 MHz Two-port non-pipelined ECC mode, non-pipelined, and read-before-
write
The following table lists the maximum operating frequency (F
MAX
) of the µSRAM block for Extended
Commercial (E), Industrial (I), Military (M), and Automotive (T2) temperature grades.
–STD speed grade is oered for Extended Commercial (E), Industrial (I), Military (M), and Automotive
(T2) temperature grades.
–1 speed grade is oered for Extended Commercial (E), Industrial (I), and Automotive (T2)
temperature grades only.
Table 5-33. µSRAM Performance
Parameter Symbol V
DD
= 1.0V
–STD
V
DD
= 1.0V
–1
V
DD
= 1.05V
–STD
V
DD
= 1.05V
–1
Unit Condition
Operating frequency F
MAX
400 415 450 480 MHz Write-port
Read access time Tac 2 2 ns Read-port
The following table lists the maximum operating frequency (F
MAX
) of the µPROM block for Extended
Commercial (E), Industrial (I), Military (M), and Automotive (T2) temperature grades.
–STD speed grade is oered for Extended Commercial (E), Industrial (I), Military (M), and Automotive
(T2) temperature grades.
–1 speed grade is oered for Extended Commercial (E), Industrial (I), and Automotive (T2)
temperature grades only.
