Hi-Rel Standard
Ordering Informaon
Product Specication
© 2025 Microchip Technology Inc. and its subsidiaries
DS00005937A - 16
Table 6-3. Electrical Performance Characteriscs–Models 2101, 2102, 2103, 2104, 2105, 2202, 2203, 2204, 2205
Supply Voltage Options
1
: +3.3V or +5V
Frequency
Range (MHz)
Max Current
(mA)
Max Rise/Fall
Times
2
(ns)
Duty Cycle
2
(%)
Max CMOS Load
(pF)
0.300–100 5.25V 3.465V 5 40 to 60 5.25V 3.465V
50 35 50 35
Note:
1
Waveform measurement points and logic limits are in accordance with MIL-PRF-55310, Para 3.6.20.3.
2
Tested with 15 pF.
Table 6-4. Electrical Performance Characteriscs–Model 2111
Supply Voltage Options: +3.3V, +5V, +12V or +15V
Frequency
Range (MHz)
Max Current
(mA)
Min Power Out
(dBm)
Harmonics/
Subharmonics
(>75 MHz) (dBc)
Spurious
(dBc)
10–225 3.3V/5V 12V/15V 3.3V/5V 12V/15V < -20 < -70
20 35 +3 +7
Table 6-5. Electrical Performance Characteriscs–Models 2112, 2114, 2115, 2212, 2214, 2215
Supply Voltage Options: +3.3V, +5V, +12V or +15V
Frequency
Range (MHz)
Max Current
(mA)
Min Power Out
(dBm)
Harmonics/
Subharmonics
(>75 MHz) (dBc)
Spurious
(dBc)
10–150 3.3V/5V 12V/15V 3.3V 5V 12V/15V < -20 < -70
20 35 0 +3 +7
Table 6-6. Electrical Performance Characteriscs–Models 2113, 2213
Supply Voltage Options: +12V or +15V
Frequency
Range (MHz)
Max Current
(mA)
Min Power Out
(dBm)
Harmonics/
Subharmonics
(>75 MHz) (dBc)
Spurious
(dBc)
10–500 12V 15V 12V 15V < -20 < -70
25 35 +5 +7
Table 6-7. Electrical Test Parameters
Operation Listing Requirements and Conditions
Input Current MIL-PRF-55310, Para 4.8.5.1
Initial Accuracy at Reference Temperature MIL-PRF-55310, Para 4.8.6
Output Logic Voltage Levels MIL-PRF-55310, Para 4.8.21.3
Rise and Fall Times MIL-PRF-55310, Para 4.8.22
Duty Cycle MIL-PRF-55310, Para 4.8.23
Overvoltage Survivability MIL-PRF-55310, Para 4.8.4
Initial Frequency – Temperature Accuracy MIL-PRF-55310, Para 4.8.10.1
Frequency – Voltage Tolerance MIL-PRF-55310, Para 4.8.14
Start-up Time (Fast/Slow Start) MIL-PRF-55310, Para 4.8.29
