Hi-Rel Standard
Quality Assurance Provisions and Vericaon
Product Specication
© 2025 Microchip Technology Inc. and its subsidiaries
DS00005882A - 10
4.2 Oponal Design, Test, and Data Parameters
The following is a list of design, assembly, inspection, and test options that can be selected or added
by purchase order request.
a. Design Pedigree (choose one as the 5
th
character in the part number):
Table 4-2. Design Pedigree
Design Pedigree Description
E
Enhanced Element Evaluation, (MIL-PRF-38534 Rev L for Class K components as specied in
DOC208191) 100 krad die, Premium Q Swept Quartz
F Hi-Rel design with 300 krad Class K die, Premium Q Swept Quartz
V Hi-Rel design with 100 krad Class K die, Non-Swept Quartz
D Hi-Rel design with Non-Swept Quartz and commercial grade components
b. Input Voltage, A for +5.0V, B for +3.3V, C for +2.5V, D for +1.8V as the 14
th
character
c. Not Used
d. Radiographic Inspection
e. Group C Inspection: In accordance with MIL-PRF-55310, Rev E (requires 8 destruct specimens)
f. Group C Inspection: MIL-PRF-55310, Rev F (requires 8 destruct specimens, includes Random
Vibration, MIL-STD-883, Method 1014 Leak Test and Life Test)
g. Group C Inspection: In accordance with MIL-PRF-38534, Table C-Xc, Condition PI (requires 8
destruct specimens – 5 pc. Life, 3 pc. RGA) Subgroup 1 ne leak test to be performed per MIL-
STD-202, Method 112, Test Condition C.
h. Internal Water-Vapor Content (RGA) samples and test performance
i. MTBF Reliability Calculations
j. Worst Case Analysis (unless otherwise specied, MIL-HDBK-1547)
k. Derating and Thermal Analysis (unless otherwise specied, MIL-HDBK-1547 with T
J
Max = +105 °C;
Derated Maximum Operating Temp = T
J
Max – ΔT
J
)
l. Process Identication Documentation (PID)
m. Customer Source Inspection (pre-crystal mount pre-cap, post-crystal mount pre-cap and nal).
Due to components being mounted underneath the crystal blank, pre-crystal mount pre-cap
inspection should be considered.
n. Destruct Physical Analysis (DPA): MIL-STD-1580 with exceptions as specied in Microchip
DOC203982.
o. Qualication: In accordance with MIL-PRF-55310, Rev F, Table IV (requires 16 destruct specimens).
Includes Group III, SG1 through SG6 only. ESD (SG7) not performed.
p. Qualication: In accordance with EEE-INST-002, Section C4, Table 3, Level 1 or 2 (requires 11
destruct specimens)
q. High Resolution Digital Pre-Cap Photographs (20 Megapixels minimum)
r. Hot solder dip of leads with Sn63/Pb37 solder prior to shipping.
s. As Designed Parts, Materials and Processes List
4.2.1 NASA EEE-INST-002 Compliance
A combination of Design Pedigree R, Option S Screening, and Qualication per EEE-INST-002, Section
C4, Table 3, meet the requirements of Level 1 and Level 2 device reliability.
