XTreme-EFIS Operating Manual Page 33
RPM and MAP enabled.
RPM only enabled
MAP only enabled
3.12.3 Volts, OAT, Oil Temperature/Pressure, Current and Auxiliary Analog section
This section displays the supply voltage, OAT, oil temperature, oil pressure, as well as the 2 auxiliary analog channels.
The oil temperature/pressure as well as the 2 auxiliary analog channels can be configured in the “EMS SETUP” menu.
3.12.4 Fuel display section
The XTreme supports dual fuel flow and dual fuel levels. The fuel section will automatically try and maximize the display
area according to the fuel parameters selected. The XTreme has 20 different fuel modes of operation. The fuel
parameters can be configured in the “FUEL SETUP” menu. See section 0.0 for more information.
3.12.4.1 Single fuel flow and calculated tank level (single tank)
Single fuel flow and fuel level sender (single tank)
Differential fuel flow and calculated tank level (single tank)
Differential fuel flow and fuel level sender (single tank)
Summed fuel flow and calculated tank level (single tank)
Summed fuel flow and fuel level sender (single tank)
