XTreme-EFIS Operating Manual Page 24
Timer:
The Timer can be configured in the quick select menu.
Hobbs:
The XTreme contains a password protected Hobbs timer. The Hobbs time can be set to the current known engine time in
the “TIMERS SETUP” menu. The Hobbs timer will only increment when the RPM is greater then the “HOBBS MINIMUM
RPM”.
Maintenance:
This timer is set in engine hours and it will count down to zero when the engine RPM is greater then the “HOBBS
MINIMUM RPM” value as set in the “TIMERS SETUP”. A good use for this function is to set the hours until your next
spark plug change or engine inspection.
The purpose of this function is to assist you in determining remaining hours until maintenance will be required. It is not
intended as a replacement for the aircraft's maintenance log. It is therefore important that the aircraft's maintenance log
be maintained in the normal manner. You should further use your own discretion in performing maintenance earlier than
indicated should any aircraft performance problems arise.
A maximum of 999 hours can be entered as a maintenance interval. A
reminder message will appear on startup when zero hours are
remaining. The reminder message will automatically disappear after 10
seconds or if the pilot presses any key. Engine running time for the
purpose of the maintenance timer is defined as the run time where the engine RPM is greater than the “HOBBS
MINIMUM RPM” value as set in the “TIMERS SETUP”.
Airframe:
This timer operates similar to the engine maintenance timer but is based on flight time. You might use it to schedule
thorough airframe checks at intervals..
A reminder message will appear on startup when zero hours are remaining. The
reminder message will automatically disappear after 10 seconds or if the pilot
presses any key.
3.8.11 Information area 2
Volts:
The XTreme can measure the supply voltage up to 30Vdc. The supply volts parameters can be configured in the “VOLTS
SETUP” menu.
OAT:
Outside air temperature can be measured using the external temperature probe. The OAT parameters can be configured
in the “OAT SETUP” menu.
Glide Ratio:
Glide ratio can be measured up to 1:99. Glide ratio is measured as a ratio between forward movement of the aircraft vs.
vertical sink rate. Please note that the forward movement of the aircraft is not synonymous with horizontal forward
movement relative to the earth surface but is a function of airspeed.
