XTreme-EFIS Operating Manual Page 23
3.8.4 Ground Speed
This is located in the top left corner of the VFR display. The ground speed value will only be displayed when a valid 2D or
3D GPS fix has been achieved.
3.8.5 True Airspeed (TAS)
Please see section 3.1.4 for more information.
3.8.6 GPS Fix Status
GPS fix status. AQ=acquiring (Red text color), 2D=2D fix, 3D=3D fix.
3.8.7 Density Altitude
Please see section 3.1.9 for more information.
3.8.8 Wind speed and Direction
Please see section 3.1.14 for more information.
3.8.9 Heading Box
The heading is corrected for attitude while pitching and rolling (MGL Avionics AHRS unit required (SP4/SP5/SP7)).The
Compass parameters can be configured in the “COMPASS SETUP” menu. The heading source of information can be
from a magnetic sensor (MGL Avionics SP2/6) or from the coarse over ground value from the GPS receiver. When the
heading source of information is from the GPS receiver then the heading will be displayed in magenta.
3.8.10 Information display area 1
Flight Time:
The flight time is automatically reset to zero when a new flight is started (manual or automatic flight detection). The text
“FLIGHT TIME” will flash when a flight is active. The flight timer can be started in the quick select menu (Manual flight
mode).
Zulu Time:
This is also know as UTC or GMT time. The RTC (real time clock) can be selected to either use the internal RTC or from
the GPS (external or internal). The RTC can be setup in the “TIMERS SETUP” menu.
Local Time:
Local time normally includes an offset from Zulu time. The time offset can be setup in the “TIMERS SETUP” menu.
