XTreme-EFIS Operating Manual Page 15
3.4.4.5 Single fuel flow only indicator
This mode is displayed if either fuel flow 1 or fuel flow 2 is selected and no fuel level senders are selected.
3.4.4.6 Dual fuel flow indicator
This mode is displayed if both fuel flow 1and fuel flow 2 are selected and the fuel mode is selected for dual flow. Both fuel
level senders are disabled.
3.4.4.7 Single tank level indicator
This mode is displayed if either fuel level 1 or fuel level 2 is selected. Both fuel flow senders are disabled.
3.4.4.8 Dual tank level indicator
This mode is displayed if both fuel level 1 and fuel level 2 are selected. Both fuel flow senders are disabled.
3.4.4.9 Differential/Summed fuel flow
This mode is displayed if both fuel flow 1 and fuel flow 2 are selected and the fuel mode is selected for either differential
or summed.
3.4.5 EGT/CHT display section
The XTreme supports up to 12 thermocouples for EGTs/CHTs. The EGT/CHT section will
automatically try and maximize the display area according to the number of EGTs/CHTs
selected. The EGT/CHT parameters can be configured in the “EGT SETUP” and “CHT SETUP”
menu.
