XTreme-EFIS Operating Manual Page 13
3.4 EFIS/EMS Display
The EFIS/EMS displays the EFIS in a 2/3 screen format and the engine data in a 1/3 screen format.
3.4.1 EFIS Display
The 2/3 EFIS display is in the same layout format as the full EFIS display. Please see the section 3.1 for more
information.
3.4.2 RPM/Rotor/MAP display section
The RPM/Rotor/MAP section will maximize the space according to which parameter is enabled. The RPM,Rotor and MAP
parameters can be configured in the “EMS SETUP” menu.
RPM,Rotor and MAP enabled.
RPM and MAP enabled.
RPM only.
MAP only.
If the RPM,Rotor and MAP displays are disabled then the Hobbs, maintenance and airframe
timers will be shown.
3.4.3 Oil Temperature, Oil Pressure, Current and Auxiliary analog display section
