Vega TP-3 Operating Manual Page 9
4.2.2 Temperature Setup
Mode:
Select the function for the analog channel. Options are “PRESSURE”, “TEMP”, “CURRENT”, “VOLTS” or “OFF”.
Sender:
Select what type of sender you are using. Select “VDO 120” for a VDO 120 degree NTC sender, Select “VDO 150” for a
VDO 150 degree NTC sender, “WESTACH” for Westach 339 NTC sender, “MGL” for a MGL NTC sender, “LM335” for a
MGL precision temperature sender or “USER” for a custom sender.
If the sender type is set to “USER"
CALIBRATE SENDER:
If the sender type is set to “USER”, then use this menu option to calibrate your pressure sender. See section 4.2.3 for
more information.
If the sender type is set to “LM335"
LM335:
If the sender type is set to LM335, then use this menu option to calibrate your LM335 precision temperature sender. If
recalibration is required then adjust the value until the temperature matches the reference ambient temperature. Please
note that the LM335 can only be calibrated in degrees Celsius irrespective if the TP-3 is setup to display temperature in
Fahrenheit.
Menu options for all sender types
Label:
Enter a label to suit your temperature channel so you can identify it easily.
Temp Unit:
Select whether you want the temperature to be displayed in degrees Celcius (ºC) or in degrees Fahrenheit (ºF).
Display Max:
Select the maximum temperature that you want the bargraph to show. This can give you increased display resolution.
