Vega TP-3 Operating Manual Page 19
7 Specifications
Operating Temperature Range -10ºC to 60ºC (14ºF to 140ºF)
Storage Temperature Range -20ºC to 80ºC (-4ºF to 176ºF)
Humidity <85% non-condensing
Power Supply
8 to 30Vdc SMPS (switch mode power supply) with built in 33V over
voltage and reverse voltage protection
Current Consumption
Approx. 73mA @ 13.8V (backlight highest setting), 33mA @13.8V
(backlight lowest setting)
Display
1.8” 160x128 pixel active matrix TFT display.
1000 cd/m2
Sunlight readable with anti-glare coating
LED Backlight is user configurable
Alarm Output
Open collector transistor switch to ground
Maximum rating 0.25A
ADC 12 bit
Dimensions see Vega series dimensional drawing
Enclosure 2 1/4” (57mm) ABS, black in color, front or rear mounting. Flame retardant.
Weight Approx. 120 grams (Instrument excluding cables)
Non-volatile memory storage 100000 write cycles
Analog Input Channels
4x Total. 3x with dipswitch programmable pullup resistor, 1x with fixed pull
up resistor
Pressure Sensors
VDO Resistive Sender: The TP-3 supports the VDO 2, 5 and 10 Bar
senders. VDO pressure senders used to measure fuel pressure require the
fuel isolation kit available from VDO.
Rotax 4-20mA Sender: The TP-3 supports the 4-20mA pressure
sender as used in Rotax 912 / 914 engines.
Voltage Output Pressure Senders: e.g. UMA senders that output
a voltage signal. A 0.5-4.5V sender selection is also available.
UMA N/T 1EU07G(M): 7PSI (0.5Bar) for carburated engine (Rotax)
UMA N/T 1EU35G(M): 35PSI (2.4Bar) for carburated engine
(Lycoming/Continental)
UMA N/T 1EU100G(M): 100PSI (6.9Bar) for injected (Lycoming /
Continental)
(M) is MGL modified senders
The TP-3 includes linearisation curves for the UMA N/T 1EU07, N/T
1EU35, N/T 1EU70, N/T 1EU70A, N/T 1EU100 and N/T 1EU150 pressure
senders
User defined senders: TP-3 has a user sender calibration feature
that can be customized for senders not listed above.
Temperature Sensors
VDO Resistive Senders: VDO 120ºC and VDO 150ºC thermistor
senders supported.
MGL NTC Resistive Sender: Echlin TS920SA (32040) automotive
temperature sender
MGL Precision LM335 semiconductor: Based on ON
Semiconductors LM335 temperature sensor
