11
C5 4 Series Insulation Armour Plus
Hot Food Holding Cabinets
L01-581
C5 4 SERIES SERVICE AND REPLACEMENT PARTS*
WARNING: Only factory approved service agents must attempt to service, repair or replace electrical components,
wiring or power cord.
CONTROL PANEL CABINET BODY
Item# Replacement Part No. Description Item# Replacement Part No. Description
1 RPC13-721 Thermostat 22 RPC02-381 2" Swivel Caster (Under Counter)
2
RPC09-213 Thermostat Mounting Cup RPC02-382 2" Swivel, Brake Caster (Under Counter)
3
RPC06-913 Knob B5DN 5" Swivel Caster
4
RPC13-375 Master Switch B5DNB 5" Swivel, Brake Caster
5
RPC13-218 Analog Thermometer RPQC02-247 6" Swivel Caster
6
RPC13-246 Amber Indicator Light RPQC02-248 6" Swivel, Brake Caster
7
RPC13-245 Red Indicator Light
22A
B5DNR 5" Rigid Caster
TOP MODULE
22B
RPC5-SSLEG-1 Stationary Equipment Leg (Qty.1)
8 RPC11-191 Intake collar 24 RPC54-8-REDPNLF
RPC54-9-REDPNLF
Armour Panel with Screws
(FOR PANEL IDENTIFICATION SEE CHART)
9 RPC13-685 Blower 120V 25 RPC53-HGRKIT Replacement Rack Hanger Kit
9A RPHX20-2103 Blower 220-240V 50/60 HZ 26 RPC54-9-URACK Full Height Universal Slide Assembly
10 RPC13-114 Element 120V, 1360W RPC54-8-URACK 5/6 Height Universal Slide Assembly
10A RPC13-1109 Element 240V, 1360W RPC54-5-URACK 1/2 Height Universal Slide Assembly
11 RPC13-198 Thermal Cutout RPC54-3-URACK Under Counter Universal Slide Assembly
12 RPC13-348 Power Cord 125V 15A Right Angle Plug 27 RPC54-9-LRACK Full Height Lip Load Slide Assembly
RPC13-337 Power Cord, 125V, 15A Twist Lock Plug RPC54-8-LRACK 5/6 Height Lip Load Slide Assembly
RPC13-289 Power Cord, 125V, 15A Straight Plug RPC54-5-LRACK 1/2 Height Lip Load Slide Assembly
12A RPC13-247 Power Cord, 250V, 15A Straight Plug RPC54-3-LRACK Under Counter Lip Load Slide Assembly
13 RPC13-083 Strain Relief 28 C5-USLIDEPR-C
Chrome Wire Slide, 1 Pair
14 RPC13-096 Terminal Block C5-USLIDEPR-S
Stainless Steel Wire Slide, 1 Pair
15
RPC07-055 Sensor Cable Grommet
29
RPC54-9-UNIVUP Individual Full Height and 1/2 Height Universal Upright
16 RPC5-SCLP Sensor Clamps and Screw RPC54-8-UNIVUP Individual 5/6 Height Universal Upright
CABINET BODY
RPC54-3-UNIVUP Individual Under Counter Universal Upright
17
RPC06-1130A Full Height Door Gasket
30
RPC54-TRVL Travel Latch
RPC06-1130B 5/6 Height Door Gasket
31
C5-SHELF-S Wire Shelf (Used with Universal Uprights)
RPC06-1130C 1/2 Height and Dutch Door Gasket
RPC06-1130D Under Counter Door Gasket
18 RPC54-9SFS-DOOR Solid Full Height Door Assembly
RPC54-8SFS-DOOR Solid 5/6 Height Door Assembly
RPC54-3SFS-DOOR Solid Under Counter Door Assembly
RPC54-3SFC-DOOR Clear Under Counter Door Assembly
18A RPC54-9SDS-TDOOR Solid Top Dutch Door Assembly
RPC54-9SDC-TDOOR Clear Top Dutch Door Assembly
18B
RPC54-9SDS-BDOOR Solid Bottom Dutch and 1/2 Height Door Assembly
RPC54-9DC-BDOOR
Clear Bottom Dutch Door Assembly
19 RPC14-118A Door Latch Flush Handle
20
RPC54-BOTHINGEASY Bottom Hinge Assembly
21 RPC54-TOPHINGEASY Top Hinge Assembly
*CHECK DATA PLATE ON REAR OF CABINET TO CONFIRM CABINET VOLTAGE BEFORE SELECTING PARTS
ARMOUR PANEL IDENTIFICATION
Height Top Panel Bottom Panel
Full Height RPC54-9-REDPNLF RPC54-9-REDPNLF
5/6 Height RPC54-8-REDPNLF RPC54-9-REDPNLF
1/2 Height --- RPC54-9-REDPNLF
Under Counter --- RPC54-8-REDPNLF
