386.257.1187
|
MetraOnline.com
6
CONNECTIONS (CONT.)
INSTALLING THE AXXESS INTERFACE
AND AX-HYKIA-SPDIF
3.5mm jack steering wheel control retention:
The 3.5mm jack is to be used to retain audio controls on the steering wheel.
• For the radios listed below: Connect the
female 3.5mm connector with stripped leads included
with the Axxess interface
, to the male 3.5mm SWC jack from the wiring harness included with
the kit. Any remaining wires tape off and disregard:
•
Eclipse: Connect the steering wheel control wire, normally Brown, to the Brown/White wire
of the connector. Then connect the remaining steering wheel control wire, normally Brown/
White, to the Brown wire of the connector
.
•
Metra OE:
Connect the steering wheel control Key 1 wire
(Gray)
to the
Brown
wire.
•
Kenwood or select JVC with a steering wheel control wire:
Connect the
Blue/Yellow
wire
to the
Brown
wire.
Note: If your Kenwood radio auto detects as a JVC, manually set the radio type to
Kenwood.
See the instructions under changing radio type.
•
XITE:
Connect the steering wheel control SWC-2 wire from the radio to the
Brown
wire.
•
Parrot Asteroid Smart or Tablet:
Connect the 3.5mm jack into the AX-SWC-PARROT (sold
separately), and then connect the 4-pin connector from the AX-SWC-PARROT into the radio.
Note: The radio must be updated to rev. 2.1.4 or higher software.
•
Universal “2 or 3 wire” radio:
Connect the steering wheel control wire, referred to as Key-A
or SWC-1, to the
Brown
wire of the connector. Then connect the remaining steering wheel
control wire, referred to as Key-B or SWC-2, to the
Brown/White
wire of the connector. If
the radio comes with a third wire for ground, disregard this wire
.
Note: After the interface
has been programmed to the vehicle, refer to the manual provided with the radio for
assigning the SWC buttons. Contact the radio manufacturer for more information
.
• For all other radios: Connect the 3.5mm jack from the wiring harness included with the kit into
the jack on the aftermarket radio designated for an external steering wheel control interface.
Refer to the aftermarket radios manual if in doubt as to where the 3.5mm jack goes to.
With the key in the off position:
1. Connect the 16-pin harness with stripped leads, and the 7386 harness, into the
Axxess interface.
2. Connect the 7386 harness to the AX-HYKIA-SPDIF interface.
3. Connect the 7386 harness to the climate display.
4. Locate the factory antenna connector in the dash and complete all necessary connections
to the radio.
Attention! If retaining steering wheel controls, ensure that the SWC jack/wire is connected to
the radio before proceeding. If this step is skipped, the Axxess interface will need to be reset for
the steering wheel controls to function.
