99-6525
5
Axxess Interface Installation
• Provides accessory power (12-volt 10-amp)
• Retains R.A.P. (retained accessory power)
• Used in non-amplified systems
• Provides NAV outputs (parking brake, reverse, and speed sense)
• Prewired ASWC-1 harness included (ASWC-1 sold separately)
• High level speaker input
• Retains balance and fade
• Ability to add aftermarket backup camera and additional video input
• Retains factory screen
• Micro “B” USB updatable
FEATURES
• Cutting tool • Crimping tool • Tape
• Connectors (example: butt-connectors, bell caps, etc.)
TOOLS REQUIRED
• Axxess Interface
• 16-pin harness with stripped leads
• 6525 harness with stripped leads
INTERFACE COMPONENTS
Connections to be made
From the 16-pin harness to the aftermarket radio:
• Connect the (2) Red wires to the accessory wire. Note: If using an ASWC-1 (sold
separately), there will be a Red wire there to connect as well.
• Connect the Orange/White wire to the illumination wire. (If the aftermarket radio
has no illumination wire, tape off the Orange/White wire.)
• Connect the Blue/White wire to the amp turn-on wire.
The following (3) wires are for aftermarket multimedia/navigation radios that provide
these wires (if not required, tape them off and disregard them).
• Connect the Light Green wire to the parking brake.
• Connect the Blue/Pink wire to the VSS or speed sense wire.
• Connect the Green/Purple wire to the reverse wire.
• Tape off and disregard the Brown, White, White/Black, Gray, Gray/Black,
Purple, Purple/Black, Green, and Green/Black wires, they will not be used in
this application. Plug the 16-pin harness into the interface.
