9
REV. 11/8/24 INST99-5865CH
CONNECTIONS TO BE MADE (CONT.)
9
3.5mm jack - steering wheel control retention:
The 3.5mm jack is to be used to retain audio controls on the steering wheel control.
• For the radios listed below: connect the included female 3.5mm connector with stripped leads, to
the male 3.5mm SWC jack from the car side harness. Any remaining wires tape off and disregard.
• Eclipse: Connect the steering wheel control wire, normally Brown, to the Brown/White wire of
the connector. Then connect the remaining steering wheel control wire, normally Brown/White,
to the Brown wire of the connector.
• Metra OE: Connect the steering wheel control Key 1 wire (Gray) to the Brown wire.
• Kenwood or select JVC with a steering wheel control wire: Connect the Blue/Yellow wire to the
Brown wire.
Note: If the Kenwood radio auto detects as a JVC, manually set the radio type to Kenwood.
See the instructions under changing radio type
.
• XITE: Connect the steering wheel control SWC-2 wire from the radio to the Brown wire.
• Parrot Asteroid Smart or Tablet: Connect the 3.5mm jack into the AX-SWC-PARROT
(sold separately), and then connect the 4-pin connector from the AX-SWC-PARROT into the radio.
Note: The radio must be updated to rev. 2.1.4 or higher software.
• Universal “2 or 3 wire” radio: Connect the steering wheel control wire, referred to as Key-A or
SWC-1, to the Brown wire of the connector. Then connect the remaining steering wheel control wire,
referred to as Key-B or SWC-2, to the Brown/White wire of the connector. If the radio comes with a
third wire for ground, disregard this wire.
Note: After the interface has been programmed to the vehicle, refer to the manual provided with
the radio for assigning the SWC buttons. Contact the radio manufacturer for more information.
• For all other radios: Connect the 3.5mm jack into the port on the radio designated for an external
steering wheel control interface. Refer to the manual provided with the radio if in doubt as to where
the 3.5mm jack goes to.
OE Backup Camera Retention:
• Connect one side of the supplied camera retention harness to the 12-pin or 54-pin
connector in the vehicle. This connector was removed from the factory 4” screen.
• Connect the two pin plug to the 14-pin AUX plug (LD-FD-AUX)
• Connect the Yellow RCA jack to the backup camera input from the aftermarket radio.
Backup Camera Retention Harness Applications:
• 2015-2018 12-PIN (LD-FDCAM-12)
• 2019-UP 54-PIN (LD-FD54CAM)
