7
REV. 6/27/22 INST99-5855CH
CONNECTIONS (CONT.)
OE Backup camera retention:
• Connect the supplied camera retention harness to the 12-pin connector in the vehicle. This is the
connector that was removed from the 4" screen.
• Connect the Yellow RCA jack to the backup camera input from the aftermarket radio.
From the 14-pin harness with stripped leads to the aftermarket radio:
The following wire is for triggering a relay from the buttons on the face of the kit. The output is latching
which means they will stay active until the button is pressed again (or until the key has been turned off).
This can be used to turn on items such as accent lighting, or fans to cool aftermarket amplifiers.
• Connect the Blue/Red wire labeled “AUX 1” to the negative input from an automotive SPDT relay
(sold separately).
USB retention
Remove the OE USB from the center console. Unplug.
Route the cable from the back plate mount base and snap the usb port into the base
Put clips on the trim and snap into the base. Snap assembly into the car.
Route cable to radio and connect available options.
1. Using the panel removal tool pry off the media
hub bezel.
2. Slide the media hub out from the opening.
3. Disconnect the (2) electrical connectors.
3.5mm jack - Steering Wheel Control retention:
The 3.5mm jack is to be used to retain audio controls on the steering wheel control.
• For the radios listed below: Connect the female 3.5mm connector with stripped leads to the male 3.5mm
SWC jack from the AXSWC harness. Tape off and disregard remaining wires.
Eclipse: Connect the SWC wire, Brown to the Brown/White wire of the connector. Then connect the
remaining SWC wire, Brown/White to the Brown wire of the connector.
Metra OE: Connect the SWC
(Key 1)
wire Gray to the Brown wire.
Kenwood or select JVC with a SWC wire: Connect the Blue/Yellow wire to the Brown wire.
Note: If the Kenwood radio auto detects as a JVC, manually set the radio type to Kenwood. See the
instructions under Changing Radio Type.
XITE: Connect the SWC
(SWC-2)
wire from the radio to the Brown wire.
Parrot Asteroid Smart or Tablet: Connect the 3.5mm jack into the AXSWCH-PAR (sold separately), and
then connect the 4-pin connector from the AXSWCH-PAR into the radio.
Note: The radio must be updated to rev. 2.1.4 or higher software.
Universal “2 or 3 wire” radio: Connect the SWC wire,
(Key-A or SWC-1)
to the Brown wire of the
connector. Then connect the remaining SWC wire,
(Key-B or SWC-2)
to the Brown/White wire of the
connector. If the radio comes with a third wire for ground, disregard this wire.
Note: After the interface has been programmed to the vehicle, refer to the manual provided with the
radio for assigning the SWC buttons. Contact the radio manufacturer for more information.
For all other radios: Connect the 3.5mm jack into the port on the radio designated for an external SWC
interface. Refer to the manual provided with the radio, if in doubt as to where the 3.5mm jack connects.
