CONNECTIONS
From the 16-pin harness with stripped leads to the aftermarket radio, connect as indicated:
• Red wire to the accessory wire.
• Orange/White wire to the illumination wire. (if applicable).
• Gray wire to the right front (+) speaker output.
• Gray/Black wire to the right front (-) speaker output.
• White wire to the left front (+) speaker output.
• White/Black wire to the left front (-) speaker output.
The following (3) wires are only for multimedia/navigation radios that require these wires.
• Blue/Pink wire to the VSS/speed sense wire.
• Green/Purple wire to the reverse wire.
• Light Green wire to the parking brake wire.
Tape off and disregard the following wires, they will not be used in this application:
Blue/White, Green, Green/Black, Purple, Purple/Black, Brown
From the car side harness to the aftermarket radio, connect as indicated:
• Black wire to the ground wire.
• Yellow wire to the battery wire.
• Green wire to the left rear (+) speaker output.
• Green/Black wire to the left rear (-) speaker output.
• Purple wire to the right rear (+) speaker output.
• Purple/Black wire to the right rear (-) output.
• Blue wire to the power antenna wire.
Disregard the following:
• Red and White RCA’s labeled FROM 3.5 & RSE/SYNC/SAT
• 6-pin male MicroFit connector
Continued on the next page
