REV. 6/22/2021 INST99-5853CH
(Figure B)
(Figure A)
KIT ASSEMBLYKIT PREPARATION
ISO DIN radio provision with pocket
1. Attach the pocket to the radio brackets
using (4) #8 x 3/8” Phillips truss-head
screws provided. (Figure A)
2. Remove the metal DIN sleeve and trim
ring from the aftermarket radio.
3. Slide the radio into the bracket/pocket
assembly, then secure it using screws
supplied with the radio. (Figure B)
Continue to Axxess
Interface Installation
(Figure B)
(Figure A)
1. Attach (4) panel clips provided on to the
radio trim panel. (Figure A)
2. For models with heated seats:
Clip in the heated seat buttons.
(Figure B)
For models without heated seats:
Clip in the blank panels. (Figure B)
Continue to Kit Assembly
