Je bekijkt pagina 6 van 20
386.257.1187
|
MetraOnline.com
6
KIT PREPARATION (CONT.)
(Figure E) (Figure F)
10.
Line up the (2) locater pins in the gear
mechanism to the circuit board, and in
the same motion, attach it to the support
brace. Secure it to the
support brace
using (2) #4 X 3/8” Phillips pan-head
screws provided. Do the same for both
sides. (Figure E)
11. Flip the circuit board over, then secure
the gear mechanism to the circuit board
using the factory screws. (Figure E)
12. One at a time, place the climate knobs
into the climate knob cavity, lining it
up with the gear mechanism. Make
sure they are placed correctly. The
“snowflake” button should be placed
on the right side (passenger side). Flip
the circuit board over while holding the
knob, then secure it to the circuit board
using (2) #4 X 3/8” Phillips
pan-head
screws provided. Do the same for the
other knob. (Figure F)
Note: The factory screws may also
be used.
Continued on the next page
