REV.
11/4/22
INST99-3018
5
KIT PREPARATION
1. Remove (4) Phillips screws to remove
the ashtray/pocket from the bottom of
the radio/climate control panel.
(Figure A)
2. Remove (4) T-10 Torx screws and (16)
Phillips screws to remove the radio/
climate controls, and radio/climate bezel
from the panel. (Figure B)
Note: The radio/climate bezel will not be
used in this installation.
3. Remove (4) Phillips screws to remove
the upper screen trim panel.
4. Cut the radio/climate control panel clock
support area as shown in the diagram.
(Figure C)
Note: Vent removal is optional.
5. Using either the factory hardware or the
(8) #8 x 3/8” Phillips pan-head screws
provided, secure the
99-3018 radio trim
pane
l and factory components to the
modified factory panel. (Figure D and E)
6. Use the (2) supplied
plastic washers
on
the top two mounting positions.
(Figure F)
7. Connect the left and right climate control
connectors to the radio/climate control
panel. (Figure G)
Continue to Kit Assembly
(Figure A) (Figure E)
(Figure D)
(Figure B) (Figure F)
(Figure C) (Figure G)
Remove shaded area
