11
REV. 4/24/2025 INST95-6560B
I N STALL ATI O N
With the vehicle completely off:
1. Connect 16-pin connector to interface
2. Connect 22-pin connector to interface
3. From the vehicle & hazard harnesses, connect the 2-pins (labeled :1) to each other.
4. Connect main harness to vehicle
5. Connect the 12-pin of the hazard harness to the HVAC LCD SCREEN
6. Locate the factory antenna connector in the dash and complete all necessary connections
to the radio. Use the antenna adapter provided to adapt the factory antenna to the
aftermarket radio.
12 Pin
Description of button Assignments
Direction of air flow
Max A/C
Driver enable/disable heated seat
Driver enable/disable cool seat
Passenger enable/disable
heated seat
Passenger enable/disable
cool seat
Enable/disable heated steering
wheel
Synchronization of
temperatures to match driver’s
Note: Heated seat, vented seat and
heated steering wheel buttons have
been included for vehicles with those
options. Blank buttons have been
included for vehicles without
those options.
