CONNECTIONS (CONT.)
From the main harness to the aftermarket radio, connect the:
• Black wire to the ground wire.
• Yellow wire to the battery wire.
• Gray wire to the front right positive speaker output.
• Gray/Black wire to the front right negative speaker output.
• White wire to the front left positive speaker output.
• White/Black wire to the front left negative speaker output.
• Connect the 4-pin harness to the main 52-pin connector:
• Green wire to the rear left positive speaker output.
• Green/Black wire to the rear left negative speaker output.
• Purple wire to the rear right positive speaker output.
• Purple/Black wire to the rear right negative speaker output.
• Yellow RCA jack to the backup camera input.
• Red & White RCA jacks to the audio AUX-IN jacks
(only if the factory AUX-IN jack is desired to be used).
• Tape off and disregard the following (2) wires, they will not be used in this application:
Blue/White labeled “500L amp turn on”, Red
• Disregard the DIN jack, it will not be used in this application.
For models
with
a factory amplifier:
From the 16-pin harness to the aftermarket radio, connect the:
• Red wire to the accessory wire.
• Blue/White wire to the amp turn on wire.
• Orange/White wire to the illumination wire (if applicable).
The following (3) wire are for multimedia/navigation radios that require them.
• Blue/Pink wire to the speed sense wire.
• Green/Purple wire to the reverse wire.
• Light Green wire to the parking brake wire.
• Tape off and disregard the following (9) wires, they will not be used in this application:
Gray, Gray/Black, White, White/Black, Green, Green/Black, Purple, Purple/Black,
Brown from the vehicle harness to the aftermarket radio:
