4
KIT PREPARATION
(CONT.)
To the radio trim panel:
Place the circuit boards, rubber keypads, and
button assemblies into the radio trim panel
in the following sequence, using the factory
hardware.
1. Place center circuit board into the radio
trim panel. (Figure A)
2. Place the top circuit board into the radio
trim panel. With the larger circuit board
flipped up, secure the (4) middle T-8
screws in the center. (Figure B)
3. Place the lower circuit board into the
radio trim panel. Secure the (2) T-8
screws at the top of the circuit board
(Figure C)
4. Rotate the larger circuit board down
and clip into position, secure the (10) T-8
screws on the outer edges of the three
circuit boards. (Figure D)
Continued on the next page
(Figure D)(Figure B)
(Figure C)(Figure A)
