REV. 5/28/2025 INST95-6559B
3
KIT PREPARATION
From the factory control panel:
1. Pull the three knobs from the front of
the factory climate controls. They come
apart in three pieces. An outer ring, a
button and a rubber keypad or two.
(Figure A)
2. Remove (8) T-8 torx screws from the
back cover. (Figure B)
3. Unclip and flip up the larger circuit
board to expose and remove (6) Torx
T-8 screws. (Figure C)
4. Remove 10 T-8 Torx screws from the
outer edges of the circuit boards.
(Figure C)
5. Remove the circuit boards, rubber
keypads, and button assemblies.
Continued on the next page
(Figure B) (Figure D)
(Figure A) (Figure C)
