INSTALLATION
Check the appliance is electrically safe when you have nished.
30
Transit bracket
Retaining
screws
Fig. 8.6
Fig. 8.7
Remove the Transit Brackets
1. Loosen the two screws in the underside of the transit
bracket (Fig. 8.6).
2. Slide the bracket forwards and remove. Discard the
Transit Bracket.
Fitting the Obscuring Trims
1. Located near the front on each side of the cooker there
are three screws. Loosen the top and bottom screws
(Fig. 8.7).
2. Slide the trim onto the screws and tighten to secure.
