17
distance from fixed or moving objects, build-ups or sources of water or other liquids,
etc.
Insert the larger diameter of the telescopic pedestal into the hole in the base, then
screw the locking ring underneath it by turning it counter-clockwise, keeping the
pedestal as upright as possible until it is fully tightened, that is, until further
tightening is met with considerable resistance.
Extract the tap screw located at the rear and bottom of the motor body, turning it
slightly counter-clockwise, until it no longer obstructs the insertion of the pedestal
in the bottom hole. If the screw starts to come out of its seat, it can be re-inserted
by resting it in the threaded hole and turning it slightly clockwise.
Fully insert the motor body onto the top of the pedestal until it stops, then secure
the motor body by turning the tap screw clockwise until rotation is met with
considerable resistance.
For greater safety, lift the entire appliance by a few centimetres and check that
none of the parts disconnect from the others. The appliance can now be put into
operation.
Head tilt: The head, that is, the top part, consisting of the cage and lamp, can be
tilted slightly upwards from the horizontal position to promote the vertical
orientation of the air flow. Assistance by a second person is recommended to adjust
the head tilt. To perform this procedure, slightly loosen (half a turn is sufficient) the
wing screw on the right-hand side immediately below the head, at which point it will
be loose enough to be tilted in the desired direction, but regardless no more than
30–35 degrees upwards. For greater dexterity, this procedure should be performed
before installing the body of the appliance on the telescopic pedestal. Once the
necessary tilt has been achieved, tighten the previously loosened screw until any
further tightening is met with considerable resistance.
Adjusting the floor-standing height: The telescopic pedestal can be adjusted to
different heights within its range to perfect the orientation of the flow. The
assistance of a second person is recommended to adjust the height of the pedestal.
To perform this operation, turn the locking flange at the bottom of the chrome-
plated section of the pedestal counter-clockwise, taking care not to unscrew the
pedestal from the base and, if the appliance is already assembled, making sure the
body of the appliance doesn't suddenly drop down. Lift or lower the body of the
appliance to the desired height. Then, holding it in position, retighten the locking
flange until it is met with considerable resistance. Although the opposite may seem
more convenient, for improved handling and safety it is advisable to carry out this
operation before the appliance is fully assembled.
