www.megger.com
PAT250SX
38
Specifications
Touch current test
Test voltage Nominal mains 230 V AC
Test frequency Nominal mains 50 Hz
Test accuracy ± 5% ± 3 digits
Resolution 0.01 mA
Display range 0.10 to 3.99 mA
Test duration User selectable from 2 sec to 5 sec
SELV device test
Test voltage 0 to 300 V AC
Measurement accuracy ± 3% ± 3 digits
Resolution 0.1 V AC
Display range 0.1 to 300 V AC
Extension lead test
Test includes Insulation and Bond tests.
Test voltage 5 V
Polarity Lead OK
Live neutral shorted
Live neutral reversed
Live/neutral open circuit
Portable RCD test
Test voltage Nominal mains 230 V
Test frequency 50 Hz
Test current accuracy +2% to +9% (1 x I, 5 x I)
Trip time accuracy ±1% ± 1 ms
Trip time resolution 0.01 ms
Display range 0 to 200 ms (1 x I)
0 to 40 ms (5 x I)
Mains supply test
Frequency measurement range 50 Hz
Test voltage 40 to 300 V AC
Accuracy ± 3% ± 3 digits
Resolution 0.1 V AC
Display range 40 to 300 V AC
Circuit test
(Carried out automatically, not available to
user)
Test voltage 5 V
Test frequency Nominal Mains 50 Hz
Test current < 100 mA short circuit
