Je bekijkt pagina 37 van 42
www.megger.com PAT250SX
37
Specifications
14. Specifications
Specification Detail
Environmental condition:
Operating ambient 20 °C
Humidity Nominal humidity
Continuity test
Test voltage Compliance Voltage: +4 V DC
-0% / +30% (open circuit)
Test current Bi-directional +100 mA
-0% +50 mA (into 2 Ω load)
Continuity accuracy Resistance: ± 5% ± 3 digits (0 to 19.99 Ω)
Resistance resolution 10 mΩ
Display range 0.01 to 19.99Ω
Continuity test nulling Up to 9.99 Ω
Test time User selectable from 2 sec to 20 sec or selected
during test to 180 sec
Insulation test
Insulation test 250 V DC –0 % /+25 % open circuit
500 V DC –0 % /+25 % open circuit
≥ 500V –0% DC across 0.5 MΩ load
Short circuit/charge current < 2 mA DC
Insulation accuracy ±3% ±10 digits (0 to 19.99 MΩ)
Resolution 0.01 MΩ
Display range 0.10 MΩ to 99.99 MΩ
Test duration User selectable from 2 sec to 20 sec or selected
during test to 180 sec
Substitute leakage test
Leakage current Accuracy ± 5% ± 3 digits
Test frequency Nominal mains frequency 50Hz
Test voltage < 50 V AC
Leakage Current Resolution 0.01 mA
Display range 0.10 to 19.99 mA
Test duration User selectable from 2 sec to 5 seconds
Reading corrected to 230V AC .
Differential leakage current
Test voltage Nominal supply voltage 230 V AC
Test frequency Nominal mains frequency 50 Hz
Test accuracy ±5% ±3d ±3uA/A
Resolution 0.01 mA
Display range 0.10 to 19.99 mA
Test duration User selectable from 2 sec to 5 seconds
