www.megger.com PAT250SX
35
Battery and Fuse replacement
12.2.1 Rechargeable batteries and battery charging
All PAT testers accept alkaline or rechargeable NiMH cells.
The PAT250SXR can be recharged using the supplied battery charger.
12.2.2 To charge the batteries:
ATTENTION : Ensure fitted batteries are of the rechargeable NiMH type.
Connect the 15 V DC plug of the charger to the socket on the connection panel of the PAT marked
WARNING : The instrument should be fully disconnected and not used during the charging process.
WARNING : Do not attempt to recharge non-rechargeable (Primary) cells. Doing so may result in
instrument damage and may cause personal injury.
WARNING : Only use a Megger approved PAT charger. Other chargers may present a fire risk.
Ensure ambient temperatures are between 4 ºC and 40 ºC while charging the PAT.
12.2.3 Fuse replacement
Possible fuse failure is indicated by the symbol.
f
For fuse replacement
Remove battery cover as above.
Withdraw fuse and check for failure.
Replace with a fuse type:
1 x 100 mA (F) 250 V 1.5 KA HBC 4 x 20 mm
