33
9. Disposal
For environmental reasons, do not dispose of
the device in the household waste.
Please dispose of the device in accordance
with EC Directive – WEEE (Waste Electrical and
Electronic Equipment).
If you have any questions, please contact the local
authorities responsible for waste disposal.
10. Troubleshooting
Problem/
question
Possible cause/remedy
The atom-
iser
does not
produce any
aerosol or
produces too
little aerosol.
1. Too much or too little medication
in the atomiser.
Minimum: 2 ml,
Maximum: 8 ml.
2. Check nozzle for blockages.
Clean nozzle if necessary (e.g.
by rinsing out). Then start the
atomiser again.
IMPORTANT: Carefully pierce the
fine holes from the underside of
the nozzle only.
3. Atomiser not held vertically.
4. Unsuitable medication fluid
added for nebulisation (e.g. too
viscous).
The medication fluid should be
prescribed by the doctor.
The output is
too low.
Kinked hose, clogged filter, too
much inhalation solution.
What medica
-
tions are
suitable for
inhaling?
Please consult your doctor in
relation to this matter.
As a rule, all medication that is
suitable and approved for device
inhalation, can be inhaled.
There is inha
-
lation solution
residue in the
atomiser.
This is normal and is necessary for
technical reasons. Stop inhalation
once the atomiser starts to make a
notably different sound.
What should
be taken into
account when
using the
device with
infants and
children?
1. On infants and children, the
mask should cover the mouth
and nose to ensure effective
inhalation.
Problem/
question
Possible cause/remedy
2. On children, the mask should
also cover both the nose and
mouth. It is not a good idea to
carry out nebulisation on some
-
one who is sleeping, as in this
case not enough of the medica
-
tion will reach the lungs.
Note: Inhalation should only be
carried out under the supervision
of an adult and with their assis
-
tance and the child should not be
left alone.
Inhalation
using the
mask takes
longer.
This is necessary for technical rea
-
sons. You breathe less medication
per breath through the holes of the
mask than via the mouthpiece. The
aerosol is mixed with ambient air
via the holes.
Why should
the atomiser
be replaced
regularly?
There are two reasons for this:
1. To ensure a therapeutically
effective particle spectrum,
the nozzle hole must not
exceed a specific diameter.
Due to mechanical and thermal
stresses, the plastic is subject
to a certain degree of wear. The
atomiser insert [10] is particularly
sensitive. This can also alter the
composition of the aerosol drop
-
lets, which directly affects the
effectiveness of the treatment.
2. Regularly changing the atomiser
is also recommended for hy
-
giene reasons.
Should each
person have
their own
atomiser?
Yes, this is absolutely essential for
hygiene reasons.
11. Technical specifications
Model
AIR PLUS
Type
GCE828
Dimensions
(W x H x D) 166 x 141 x 148 mm
Weight
1.4 kg
Operating
pressure Approx. 0.8 to 1.45 bar
Atomiser filling
volume
Min. 2 ml
Max. 8 ml
