Technical Manual Presence Detector SCN-x360xx.03
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 • Germany
Telephone: +49-2263-880 • knx@mdt.de • www.mdt.de
62
62
Forced guidance for
output value
“False/True”
• 00 - no priority, Off
• 01 - no priority, On
• 10 - priority, Off
• 11 - priority, On
Visible when “Force 2Bit” is
selected.
Setting the value to be sent
Sending condition
• on input telegram
• on output change
• send only 0 on change
of output
• send only 1 on change
of output
• send only 0 on input
telegram
• send only 1 on input
telegram
Setting the Sending Condition:
On input telegram: The output value
is sent with every input telegram,
regardless of whether the output
value has changed or not
On change of output: The output
value is only sent if the output has
changed.
Send only 1 on change of output:
The output value is only sent if the
output changes and the logic has the
corresponding value (0/1).
Send only 0/1 on input telegram:
Output value is sent with each input
telegram if the logic has the
corresponding value (0/1)
Output
• normal
• inverted
Defines how the output object is
sent.
Internal Input A/B
• not active
• normal
• inverted
Activation of an internal object as
logic input
Object number
0-99
[0]
Selection of the internal object -
Attention: Only bit values are
evaluated correctly!
External Input C-F
• not active
• normal
• inverted
Activation of an external object as
logic input
Preset logic input after
reset with
• Value 0
• Value 1
Setting of a pre-assignment of the
logic after a bus voltage recovery
Table 31: Settings – Logic
The following table shows the associated communication objects:
Number
Name
Length
Usage
110
Logic 1 – Input C
1 Bit
External input for the logic function
111
Logic 1 – Input D
1 Bit
External input for the logic function
112
Logic 1 – Input E
1 Bit
External input for the logic function
113
Logic 1 – Input F
1 Bit
External input for the logic function
114
Logic 1 – Output 1
1 Bit/
2 Bit/
1 Byte
Output of the logic function. DPT depending on
the output object parameter
Table 32: Communication objects – Logic
