Technical Manual Presence Detector SCN-x360xx.03
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 • Germany
Telephone: +49-2263-880 • knx@mdt.de • www.mdt.de
51
51
The following table shows the possible settings for constant light control:
ETS-Text
Dynamic range
[Default value]
Comment
Constant light control
• not active
• active
Activation/Deactivation of the
constant light control.
Control sunlight
• normal
• little
• very little
defines the influence of the
solar radiation to the regulation.
Selection of lighting groups
• 1 lighting group
• lighting group middle + wall
• lighting group middle +
window
• lighting group middle + wall +
window
Selection of the light bands,
which shall be controlled.
Influence of proportional
zone control - wall
• no change (x 1)
• very low (x 1,2)
• low (x 1,4)
• medium (x 1,6)
• high (x 1,8)
• very high (x 2)
Defines the influence of the
lighting group “wall” to the
constant level light regulation.
Influence of proportional
zone control - window
• no change (x 1)
• very low (x 0,9)
• low (x 0,8)
• medium (x 0,7)
• high (x 0,6)
• very high (x 0,5)
Defines the influence of the
lighting group “window” to the
constant level light regulation.
Table 26: Settings – Constant light control
The parameter "Influence of proportional zone control" specifies how strong the influence of the
lighting group on the control should be. The setting "no influence" (x 1) switches off the
proportionality of the control and all lighting groups always light up with the same value. The setting
"very strong" (0.5 for window and 2 for wall) means that the difference between the absolute
dimming values at the wall and window is very large.
If a room is to be controlled using the constant light control, it is recommended to use the Teach-in
procedure, as this is the only way to achieve good results.
The influences of the wall and window lighting groups have to be adapted to the specific conditions.
Simplified, the larger the room, the stronger the control factor has to be, i.e., the stronger the
influence has to deviate from 1. However, the parameters should always be checked on site and
corrected if necessary.
Adjustment of the control is possible via the "Control sunlight" parameter. If the Presence Detector
reduces the light in the room too much when the sun is shining, the value for this parameter should
be set to little or very little. Alternatively, the Presence Detector can also be moved further into the
middle of the room.
