Technical Manual Presence Detector SCN-x360xx.03
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 • Germany
Telephone: +49-2263-880 • knx@mdt.de • www.mdt.de
45
45
Send measured value
cyclically
not active
5 s – 30 min
Defining a fixed period of time after
which the current brightness
measurement value is sent
repeatedly
Correction Lux value
-50 % … 70 %
[0 %]
Increase/decrease by the set value
Room reflection factor
• 1
• 0,7 very high
• 0,5 high
• 0,4 medium
• 0,3 low
• 0,25 low
• 0,2 very low
Reflectance of the environment.
Indicates what percentage of the
light is reflected
(1 = 100%, 0 = 0%)
Threshold switch
• not active
• active
Activation of a threshold switch
The following parameters appear after activating the threshold switch:
Threshold switch
switches at
5 Lux– 1000 Lux
[300 Lux]
Setting of the threshold at which the
threshold switch switches over =
defined switch-on point
Hysteresis of threshold
switch
5 Lux – 200 Lux
[30 Lux]
Distance between switch-off and
switch-on point
Switch-off point = value for switching
the threshold switch - Hysteresis
Object value at “Day” and
exceedance
• ON
• OFF
Setting the value to be sent
Object value at “Night”
and exceedance
• ON
• OFF
Setting the value to be sent
Object value at lower
deviation
• ON
• OFF
Setting the value to be sent
Send at “Day”
• no active
• only ON
• only OFF
• ON und OFF
Transmit filter during daytime
operation
Send at “Night”
• no active
• only ON
• only OFF
• ON und OFF
Transmit filter during night
operation
Lux value for Teach-in
200 … 1000
[450]
Adjustment value for external read-
in.
Only for constant light control!
Teach-in value at
application download
• hold Teach in value
• use default value
Specifies whether the presence
detector should retain the Teach in
values after the download or load
the factory settings.
Only for constant light control!
Table 23: Settings – Brightness
