Technical Manual Presence Detector SCN-x360xx.03
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 • Germany
Telephone: +49-2263-880 • knx@mdt.de • www.mdt.de
24
24
As an alternative to the force control object, 1 or 2 locking objects of size 1 bit can be displayed.
3 different states can be configured for the lock object:
• Lock motion (lock current state)
The channel is locked in its current state and remains locked until the locking process is
deactivated.
• Switch ON
The light channel sends the output value ON and remains in the ON state until the locking
process is deactivated.
• Switch OFF
The light channel sends the output value OFF and remains in the OFF state until the locking
process is deactivated.
By activating "Lock object ON", the light channel sends the output value ON and remains in the ON
state until the locking process is deactivated.
With the parameter “Fallback of forced guidance/lock (general setting)”, it is possible to set
individually for each channel whether it should react to the configuration for "Fallback of forced
guidance/lock" in the "General settings" or not.
The following table shows the corresponding communication objects:
Number
Name
Length
Usage
8
Light channel 1 - Input – Lock object
1 Bit
Locking the light channel
8
Light channel 1 - Input –
Forced guidance
2 Bit
Activate/deactivate forced guidance
9
Light channel 1 - Input –
Lock object ON
1 Bit
Switching on the light channel and locking
the light channel in the ON state
68
HVAC - Input – Lock object
1 Bit
Locking the light channel
68
HVAC - Input – Forced guidance
2 Bit
Activate/deactivate forced guidance
69
HVAC - Input – Lock object ON
1 Bit
Switching on the light channel and locking
the light channel in the ON state
Table 7: Communication objects – Forced guidance/lock
