Technical Manual – LED-Indicator SCN-LED55.01/SCN-GLED1x.01
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 • Phone: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de
9
9
Logic objects:
44
Logic A
Input logic 1-8
DPT 1.001
receive
Indicator reacts
to Input-telegram
Control buttons,
status of
actuators, states
of binary
inputs,…
Input of the logic function
Eingang der Logikfunktion.
52
Logik A
Output Switching
DPT 1.001
sending
Indicator sends
current state
Visu,
Actuators …
Sends a Bit value if logic function
is satisfied
52
Logik A
Output Scene
DPT 18.001
sending
Indicator sends
current state
Visu,
Actuators …
Sends adjusted scene number if
logic function is satisfied
52
Logik A
Output Value
DPT 5.001
sending
Indicator sends
current state
Visu,
Actuators …
Sends adjusted value if logic
function is satisfied
+9
nächste Logik
Converter objects:
116
Converter module A
Input value A1
(Byte-->Bit)
DPT 5.001
receive
Indicator reacts
to Input-telegram
Actuator, Visu,
Control
Buttons…
Input of the converter module
116
Converter module A
Input A Compelled
guidance
(2 Bit-->Bit)
DPT 2.001
receive
Indicator reacts
to Input-telegram
Presence
detector,
Actuator, Visu…
Input of the converter module
116
Converter module A
Input value A1
(Temperature-->Bit)
DPT 9.001
receive
Indicator reacts
to Input-telegram
Temperature-
sensor/
controller
Input of the converter module
