Technical Manual – LED-Indicator SCN-LED55.01/SCN-GLED1x.01
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 • Phone: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de
10
10
118
Converter module A
Gate Control input A
DPT 1.009
receive
Indicator reacts
to Input-telegram
Control Buttons,
Visu
Object is used to set whether the
input value passed, or is to be
converted. When the gate is
closed, the converter is disabled.
119
Converter module A
Output value A1
DPT 1.002
sending
Indicator sends
telegram
Visu,
Actuators …
Sends 0 or 1 depending on the
preset threshold.
Active in byte -> bits and
temperature -> bit
119
Converter module A
A1: Compelled guidance
ON
DPT 1.002
sending
Indicator sends
telegram
Visu,
Actuators …
Sends 1 if Forced ON, 0 otherwise
Active with positive guidance ->
bit
120
Converter module A
A2: Compelled guidance
OFF
DPT 1.002
sending
Indicator sends
telegram
Visu,
Actuators …
Sends 1 if forced operation,
otherwise 0
Active with positive guidance ->
bit
+5
next converter module
136
Operating
Status
DPT 1.001
sending
Indicator sends
state
Visu…
Sends a "Set" message when the
device is on the bus
Table 1: Communication Objects
