The following table shows the specific settings for this controller type:
ETS-Text
Dynamic range
[Default value]
Comment
Minimum level for „Day“
Level 0 – Level 4
[Level 0]
Defines the minimum or maximum level
to be switched in "Day" or "Night"
mode.
Maximum level for „Day“
Level 0 – Level 4
[Level 4]
Minimum level for
„Night“
Level 0 – Level 4
[Level 0]
Maximum level for
„Night“
Level 0 – Level 4
[Level 4]
Threshold level 1
Threshold level 2
Threshold level 3
Threshold level 4
400 … 2000 ppm
[600]
[800]
[1000]
[1200]
0 … 500
[80]
[160]
[240]
[320]
Setting range of the threshold values at
which switching is to take place.
Unit (ppm/IAQ) depending on the
selection in "Controller actual value".
Hysteresis in
• percent
• ppm
Setting with which unit the hysteresis is
determined.
Selection depends on the setting in
"Controller actual value".
• percent
• IAQ
Hysteresis
0 … 20 %
[10 %]
Setting the hysteresis in „percent“.
10 … 500 ppm
[50 ppm]
Setting the hysteresis in „ppm“.
0 … 50
[5]
Setting the hysteresis when "IAQ" is
selected.
Control value for „Day“
(Level 1)
(Level 2)
(Level 3)
(Level 4)
0 – 100%
[25%]
[50%]
[75%]
[100%]
Setting which control value is to be sent
for the respective stage in "Day" or
"Night" mode.
Control value for „Night“
(Level 1)
(Level 2)
(Level 3)
(Level 4)
0 – 100%
[10%]
[30%]
[50%]
[70%]
Table 22: Settings – Step controller as Byte
Minimum/Maximum level for „Day“/“Night“
With these settings, the air quality control can be limited. A fixed level can be set for the respective
parameter, which cannot be exceeded or undercut.
Note: The switchover for "Day/Night" is made in the "General Settings" menu. If this is "not
active", the parameters are only called "Minimum level" or "Maximum level".
Threshold level 1 – 4
The threshold values at which the switching between the different levels is to take place are set
here.
