Je bekijkt pagina 20 van 78
Technical Manual
CO2 / VOC Combi Sensor 55 [SCN-CO2MGS.02]
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 • Germany
Phone: +49-2263-880 • knx@mdt.de • www.mdt.de
20
20
The setting "Send measured value on change" can be used to set the change on which the sensor
sends its current temperature value. If set to "not active", the sensor does not send a value,
regardless of the size of the change.
The setting "Send measured value cyclically" can be used to set the intervals at which the sensor
sends its current measured value. The cyclical sending function can be activated or deactivated
independently of the setting "Send measured value on change". Measured values are also sent if
the sensor has not detected a change. If both parameters are deactivated, a value is never sent.
Important: After reset/programming, the first measured value is sent after approx. 1 minute.
With the "Messages" function, two message values (upper and lower message value) can be
parameterized. The two functions each have their own communication object.
Principle:
If the upper message value is exceeded, a "1" is sent. If it is undershot again, a "0" is sent.
If the value falls below the lower message value, a "1" is sent. If it is exceeded again, a "0" is sent.
A correction value can be set via the parameter "Calibration value for internal sensor". This is
used to increase/decrease the actual measured value. This setting makes sense if the sensor has
been installed in an unfavourable location, such as above a radiator or in a draught area. The
temperature sensor sends the corrected temperature value when this function is activated.
An external sensor can be activated or deactivated via the weighting "Sensor internal/external". If
the weighting is set to 100% internal, no external sensor is activated and no communication object
appears for the external sensor. With any other setting, an external sensor is activated and the
associated object appears. The "mixed" value is sent to the bus via the "Send measured value"
object.
Important: The external sensor is monitored with a time of 30 minutes. If no new value is received
within this time, only the internal sensor is used!
At the same time, an alarm with a "1" is sent to the "External sensor error" object. If an external
value is received again, the alarm is reset with a "0".
The following table shows the available communication objects:
Number
Name/Object function
Length
Usage
15
Temperature measurement –
Send measured value
2 Byte
Sending the current measured value
16
Temperature measurement –
External sensor input
2 Byte
Receives the temperature of the external
sensor
17
Temperature measurement –
Maximum value exceeded
1 Bit
Sends a message if the upper message value
is exceeded
18
Temperature measurement –
Minimum value fallen below
1 Bit
Sends a message when the value falls below
the lower message value
19
Temperature measurement –
Error external sensor
1 Bit
Sends an error message if the sensor does
not send a value for a certain time
Table 12: Communication objects – Temperature measurement
