Technical Manual
Motion Detector/Automatic Switch 55/63 [SCN-BWM55/63(T)(06).x2]
State 07/2025 - Version 1.4
Standard settings – HVAC channel
No. Name Object function Length
C R W T U
60 HVAC - Output Switch 1 Bit
■ ■ ■
60 HVAC - Output Dimming absolute 1 Byte
■ ■ ■
60 HVAC - Output Scene 1 Byte
■ ■ ■
63 HVAC - Input External button short 1 Bit
■ ■
64 HVAC - Input External button long 1 Bit
■ ■
65 HVAC - Input External motion 1 Bit
■ ■
66 HVAC - Input Status of actuator channel 1 Bit
■ ■
67 HVAC - Input Lock motion detection 1 Bit
■ ■
68 HVAC - Input Forced guidance 2 Bit
■ ■
68 HVAC - Input Lock object 1 Bit
■ ■
69 HVAC - Input Lock object ON 1 Bit
■ ■
70 HVAC - Status Automatic mode 1 Bit
■ ■ ■
70 HVAC - Status Lock/Manual mode 1 Bit
■ ■ ■
72 HVAC - Input Teach-in dimming value for ON 1 Byte
■ ■ ■
73 HVAC - Input Follow-up time 10 - 65000 s 2 Byte
■ ■ ■
Table 2: Communication objects – Standard settings: HVAC channel
Standard settings – Alarm/Message channel / Direction of movement
No. Name Object function Length
C R W T U
75 Alarm - Output Switch 1 Bit
■ ■ ■
75 Alarm - Output (Day) Switch 1 Bit
■ ■ ■
76 Alarm - Output (Night) Switch 1 Bit
■ ■ ■
83 Alarm - Input Lock 1 Bit
■ ■
83 Alarm - Input Release 1 Bit
■ ■
101 Direction of movement 1 Switch when moving from right to left 1 Bit
■ ■ ■
102 Direction of movement 2 Switch when moving from left to right 1 Bit
■ ■ ■
Table 3: Communication objects – Standard settings: Alarm/Message channel / Direction of movement
