Technical Manual
Motion Detector/Automatic Switch 55/63 [SCN-BWM55/63(T)(06).x2]
State 07/2025 - Version 1.4
3 Communication objects
3.1 Standard setting of the communication objects
Standard settings – Light channels
No. Name Object function Length
C R W T U
0 Light channel 1 - Output 1 Switch 1 Bit
■ ■ ■
0 Light channel 1 - Output 1 (Day) Switch 1 Bit
■ ■ ■
0 Light channel 1 - Output 1 Dimming absolute 1 Byte
■ ■ ■
0 Light channel 1 - Output 1 Scene 1 Byte
■ ■ ■
1 Light channel 1 - Output (Night) Switch 1 Bit
■ ■ ■
2 Light channel 1 - Output 2
(Additional)
Switch 1 Bit
■ ■ ■
3 Light channel 1 – Input External button short 1 Bit
■ ■
4 Light channel 1 – Input External button long 1 Bit
■ ■
5 Light channel 1 – Input External motion (Slave) 1 Bit
■ ■
6 Light channel 1 – Input Status of actuator channel 1 Bit
■ ■
7 Light channel 1 – Input Lock motion detection 1 Bit
■ ■
8 Light channel 1 – Input Forced guidance 2 Bit
■ ■
8 Light channel 1 – Input Lock object 1 Bit
■ ■
9 Light channel 1 – Input Lock object ON 1 Bit
■ ■
10 Light channel 1 – Status Automatic mode 1 Bit
■ ■ ■
10 Light channel 1 – Status Lock/Manual mode 1 Bit
■ ■ ■
11 Light channel 1 – Input Switch dark 1 Bit
■ ■
12 Light channel 1 – Input Teach-in dimming value for ON 1 Byte
■ ■ ■
13 Light channel 1 – Input Follow-up time 10 - 65000 s 2 Byte
■ ■ ■
+15 Light channel 2 ...
Table 1: Communication objects – Standard settings: Light channels
