MDT technologies GmbH · Papiermühle 1 · 51766 Engelskirchen · Germany
Telephone: +49 (0) 2263 880 · knx@mdt.de · www.mdt-group.com
62 / 67
Technical Manual
Motion Detector/Automatic Switch 55/63 [SCN-BWM55/63(T)(06).x2]
State 07/2025 - Version 1.4
ETS Text
Dynamic range
[Default value]
Comment
Settingsif“Outputobject”→„Value“
Sending condition ■ on input telegram
■ on change of output
■ send only value for “False” on change
of output
■ send only value for “True” on change
of output
■ send only value for “False” on input
telegram
■ send only value for “True” on input
telegram
Setting the condition under which
the output is sent.
Datapoint type ■ 1 Byte DPT 5.005 Decimal factor
(0...255)
■ 1 Byte DPT 5.001 Percent value
(0...100%)
Setting the data point type for the
value to be sent.
Value for output value
“False”/”True”
0 ... 255
[0]
Setting the value to be sent.
Only with DPT 5.005
Percent value for
output value
“False”/”True”
0 % – 100 %
[0%]
Setting the value to be sent.
Only with DPT 5.001
Settingsif“Outputobject”→„Forcedguidance“
Sending condition ■ on input telegram
■ on change of output
■ send only value for “False” on change
of output
■ send only value for “True” on change
of output
■ send only value for “False” on input
telegram
■ send only value for “True” on input
telegram
Setting the condition under which
the output is sent.
Forced guidance for
output value
“False”/”True”
■ 00 - no priority, Off
■ 01 - no priority, On
■ 10 - priority, Off
■ 11 - priority, On
Setting the value to be sent.
Settings: Inputs
Internal Input A/B ■ not active
■ normal
■ inverted
Activation of an internal object as a
logic input and setting whether it
should be used normally or
inverted.
