MDT technologies GmbH · Papiermühle 1 · 51766 Engelskirchen · Germany
Telephone: +49 (0) 2263 880 · knx@mdt.de · www.mdt-group.com
61 / 67
Technical Manual
Motion Detector/Automatic Switch 55/63 [SCN-BWM55/63(T)(06).x2]
State 07/2025 - Version 1.4
Up to 4 different logic functions can be implemented. Each logic function can link and evaluate up to 2
internal objects and up to 4 external objects. The sending behaviour of the output can be adjusted via the
sending condition.
The following table shows the available settings:
ETS Text
Dynamic range
[Default value]
Comment
Function ■ AND
■ OR
■ XOR
Setting of the logic function.
Output object ■ switch
■ scene
■ value
■ forced guidance 2 Bit
Setting the output object for the
logic.
Settingsif“Outputobject”→„Switch“
Sending condition ■ on input telegram
■ on change of output
■ send only “0” on change of output
■ send only “1” on change of output
■ send only “0” on input telegram
■ send only “1” on input telegram
Setting the condition according to
which the output should send.
Output ■ normal
■ inverted
Deneshowtheoutputobjectis
sent.
Settingsif“Outputobject”→„Scene“
Sending condition ■ on input telegram
■ on change of output
■ send only scene for “False” on change
of output
■ send only scene for “True” on change
of output
■ send only scene for “False” on input
telegram
■ send only scene for “True” on input
telegram
Setting the condition under which
the output is sent.
Scene number for
output value
“False”/”True”
not active, 1 – 64
[1]
Set the scene to be sent.
