Technical Manual
Motion Detector/Automatic Switch 55/63 [SCN-BWM55/63(T)(06).x2]
State 07/2025 - Version 1.4
4.6 Brightness
The following table shows the available settings:
ETS Text
Dynamic range
[Default value]
Comment
Light channels influence
the brightness
measurement
■ yes (several lights in the room)
■ no (separate functions)
Setting whether the brightness
measurement is influenced by several
light sources in the room or not.
Correction value -50 % – 70 %
[0 %]
Increase/decrease the value to correct
the measured brightness.
Send brightness on change
of
not active, 5 % – 50%
[10 %]
Setting if the measured value is sent
when there is a percentage change.
Send measured value
cyclically
not active
5 s – 30 min
Setting for whether and at what interval
the measured value is sent cyclically.
Table 70: Settings – Brightness
Important: If the white LED is active, the brightness value is not evaluated.
Light channels influence the brightness measurement
■ Example for “yes” setting: Light channels 1 and 2 respond to the basic setting for brightness (General
settings) and switch on two independent light sources in the room. If, for example, light channel 1 is
switched on via an external button and the brightness value of the switch-on level is exceeded, the
other channel will automatically be “independent of brightness” and can thus also switch on their
lamps via motion.
■ Example for “no” setting: If several light sources are switched in a stairwell with a detector, but these
have no influence on each other due to their positions (e.g. indirect LED lighting), both light groups can
be set to the “basic setting” of the switch-on threshold. If it is now bright due to daylight and the
switch-on level is exceeded, then every indirect LED light should no longer switch on.
Correction value
This offset value is used to raise or lower the actual measured value. The “Brightness – Send measured
value” object sends the corrected brightness value.
Note: The correction value is entered as a percentage. A setting of -10% will lower the value to be sent by
40 lux if the measured value is 400 lux.
