MDT technologies GmbH · Papiermühle 1 · 51766 Engelskirchen · Germany
Telephone: +49 (0) 2263 880 · knx@mdt.de · www.mdt-group.com
28 / 67
Technical Manual
Motion Detector/Automatic Switch 55/63 [SCN-BWM55/63(T)(06).x2]
State 07/2025 - Version 1.4
4.2.1.4.4 Sending conditions for output objects
Light channel
HVAC channel
Important: Parameters for the sending conditions are only available in “fully automatic” operating mode!
The following table shows the available settings:
ETS Text
Dynamic range
[Default value]
Comment
If“ObjecttypeforoutputLight/HVAC”→“switch”
Output object 1 sends ■ only ON
■ only OFF
■ ON and OFF
Settingthesendinglter.
Output object 1 sends ON
cyclically
not active
10 s – 60 min
Setting the sending interval.
Output 2 (Additional
switch object)
■ not active
■ ON and OFF
Activation of output 2
Only for “Light channel”.
If“ObjecttypeforoutputLight/HVAC”→“dimmingabsolute”
Output object 1 sends ■ only dimming value for ON
■ only dimming value for OFF
■ dimming value for ON and OFF
Settingthesendinglter.
Output object 1 sends
value for ON cyclically
not active
10 s – 60 min
Setting the sending interval.
Output 2 (Additional
switch object)
■ not active
■ ON and OFF
Activation of output 2
Only for “Light channel”.
If“ObjecttypeforoutputLight/HVAC”→“scene”
Output object 1 sends ■ only scene number for ON
■ only scene number value for OFF
■ scene number for ON and OFF
Settingthesendinglter.
Output object 1 sends
scene for ON cyclically
not active
10 s – 60 min
Setting the sending interval.
Output 2
(Additional switch object)
■ not active
■ ON and OFF
Activation of output 2
Only for “Light channel”.
Table 27: Settings – Sending conditions for output objects
“Output object 1 sends” determines which value (according to the set object type) is to be sent.
“Output object 1 sends … ON cyclically” is used to set whether and at what interval the output object for
“ON” is to be sent cyclically.
Via “Output 2 (Additional switch object)”, an additional 1 Bit switch object can be activated for the light
channels.
Important: If output object 1 sends cyclically, output 2 (if active) is also sent cyclically at the same
interval.
