Technical Manual
Motion Detector/Automatic Switch 55/63 [SCN-BWM55/63(T)(06).x2]
State 07/2025 - Version 1.4
4.2.1.4.3 Output object: Scene
Light channel
HVAC channel
The following table shows the available settings:
ETS Text
Dynamic range
[Default value]
Comment
Scene Number for “Day”
when ON
not active, 1 – 64
[1]
Activationandspecicationofthe
scene number in Day and Night
mode.
Scene Number for “Day”
when OFF
not active, 1 – 64
[2]
Scene Number for
“Night” when ON
not active, 1 – 64
[3]
Scene Number for
“Night” when OFF
not active, 1 – 64
[4]
Table 25: Settings – Output object: Scene
Note: For the light channels, an additional “Switch” object can be displayed.
Function description
The scene numbers for Day/Night if ON/OFF are used to specify the corresponding scene which the
channel sends after a detection or after the follow-up time has elapsed.
The following table shows the associated communication objects:
No. Name/Object function Length Usage
0 Light channel 1 - Output 1 – Scene 1 Byte Sending a Scene number.
2 Light channel 1 - Output 2 (Additional)
– Switch
1 Bit Additional switching function of the light
channel.
+15 Light channel 2 ...
60 HVAC - Output – Scene 1 Byte Sending a Scene number.
Table 26: Communication objects – Output object: Scene
