Technical Manual
Motion Detector/Automatic Switch 55/63 [SCN-BWM55/63(T)(06).x2]
State 07/2025 - Version 1.4
4.2.1.2 Basic settings – HVAC channel
HVAC channel
The following table shows the available settings:
ETS Text
Dynamic range
[Default value]
Comment
Active sensors ■ - -
■ 1 -
■ - 2
■ 1 2
Setting which sensors are active for this
channel.
Information about
sensor assignment
When activated (check box selected with
a mouse click), a sketch appears with
information about the positions of
sensors S1 and S2.
Position of sensors
Channel mode ■ fully automatic
■ half automatic
(manual switching)
Setting the operating mode.
Number of monitoring
time slots
1 – 30
[3]
Setting for how many time slots are
active.
Only in channel mode “fully automatic”.
Length of monitoring
time slot
0 s ... 30000 s
[30 s]
Setting the length of the time slots.
Only in channel mode “fully automatic”.
Follow-up time “Day” 1 s – 4 h
[3 min]
Setting the follow-up time for Day/Night
mode.
Follow-up time “Night” 1 s – 4 h
[30 s]
Table 16: Settings – Basic settings: HVAC channel
Active sensors
The active sensors can be set for each channel. This allows the detection range of the channel to be
limited. For example, if only one area in a corridor is to be detected, only one sensor can be activated. The
alignmentofthesensorscanbeidentiedbyactivatingthe“Information about sensor assignment”
parameter.
Channel operating mode
■ Fully automatic: HVAC channel responds if a presence is detected and switches the output. After the
follow-up time has elapsed, the channel switches off again.
■ Half automatic: In this mode, the HVAC channel is switched on via the “External push button short”
object. The HVAC channel then remains switched on up to the point when no more presence is
detected. After the follow-up time has elapsed, the light channel then automatically switches off again.
