MDT technologies GmbH · Papiermühle 1 · 51766 Engelskirchen · Germany
Telephone: +49 (0) 2263 880 · knx@mdt.de · www.mdt-group.com
19 / 67
Technical Manual
Motion Detector/Automatic Switch 55/63 [SCN-BWM55/63(T)(06).x2]
State 07/2025 - Version 1.4
Reduction of follow-up time
If activated, two further parameters are displayed:
■ Maximum duration for short-time presence: Indicatesthedurationbetweentherstandthelast
movement detection to activate the short-time presence.
■ Follow-up time for short-time presence: Indicates the duration of the follow-up time when the
short-time presence was activated.
Iftherstandlastmovementwasdetectedwithinthesetdurationforshort-timepresencewhenshort-
time presence was activated, the output is not switched on for the regular follow-up time, but only for the
follow-up time of the short-time presence.
Object: “Lock motion detection”
The “Lock motion detection” object, which is permanently displayed, deactivates motion detection for this
light channel. In comparison to a lock via the lock object, the light channel can still be operated manually
via internal and external button functions.
The following table shows the associated communication objects:
No. Name/Object function Length Usage
6 Light channel 1 - Input –
Status of actuator channel
1 Bit Response from the actuator’s status output.
7 Light channel 1 - Input –
Lock motion detection
1 Bit Locks motion detection for this light channel.
11 Light channel 1 - Input – Switch dark 1 Bit Operates the light channel independent of
brightness.
13 Light channel 1 - Input –
Follow-up time 10 - 65000 s
2 Byte Sets the follow-up time via an external object.
+15 Light channel 2 ...
Table 15: Communication objects – Basic settings: Light channel
