MDT technologies GmbH · Papiermühle 1 · 51766 Engelskirchen · Germany
Telephone: +49 (0) 2263 880 · knx@mdt.de · www.mdt-group.com
14 / 67
Technical Manual
Motion Detector/Automatic Switch 55/63 [SCN-BWM55/63(T)(06).x2]
State 07/2025 - Version 1.4
ETS Text
Dynamic range
[Default value]
Comment
Fallback of forced
guidance/lock
■ not active
■ after presence and follow-up time
■ afterxedtime
Activation of a time for fallback from
forced guidance or lock respectively.
Follow-up time for
forced guidance/lock
“Day”/”Night”
1 s – 9 h
[3 min]
Setting a follow-up time for day/night
mode.
Only for “after presence and
follow-up time”.
Fallback time for forced
guidance/lock
“Day”/”Night”
1 s – 9 h
[10 min]
Setting a fallback time for day/night
mode.
Only for “after xed time”.
Fallback for external
button long
(Manual => Auto)
■ not active
■ after presence and follow up
time
■ afterxtime
Activation of a time for fallback from
override via an “external button ...”
object.
Manual Mode, follow-up
time for ON/OFF
“Day”/ “Night”
1 s – 9 h
[3 min]
Setting a follow-up time in manual
mode for ON/OFF in Day and Night
mode respectively.
Only for “after presence and
follow-up time”.
Manual Mode, fallback
time for ON/OFF
“Day”/ “Night”
1 s – 9 h
[10 min]
Setting a fallback time in manual
mode for ON/OFF in Day and Night
mode respectively.
Only for “after xed time”.
Table 11: General settings
Send “Operating” cyclically
The “Operating” object is used to show on the bus that the device is alive. If activated, an “ON” telegram is
sent cyclically.
Day/Night object
AftertheDay/Nightobjecthasbeenactivated,thepolaritycanbespeciedusing “Value for Day/Night”.
Regardless of this polarity, the device always starts in “Day” operation after reprogramming. You can also
specify whether the “Day/Night” Object should be requested after bus power return.
Toggle Day/Night
This is used to specify whether the Day/Night switchover is to be adopted immediately with the input
telegram or not until the next time motion (presence) is detected.
