MDT technologies GmbH · Papiermühle 1 · 51766 Engelskirchen · Germany
Telephone: +49 (0) 2263 880 · knx@mdt.de · www.mdt-group.com
56 / 67
Technical Manual
Motion Detector/Automatic Switch 55/63 [SCN-BWM55/63(T)(06).x2]
State 07/2025 - Version 1.4
4.5 Scenes
The scene function can be used to trigger actions for the light channels involved by receiving the
corresponding scene numbers.
Important: Scenes are only available for Light channels and not for the HVAC channel or Alarm channel.
Actions can only be set for Light channels that have been activated in the “Channel selection” menu.
The following table shows the available settings:
ETS Text
Dynamic range
[Default value]
Comment
Scene A - H number not active
1 – 64
Setting the scene number.
Scene A - H
Light channel 1 / 2
■ not active
■ lock active, ON
■ lock active, OFF
■ lock active
■ lock disable (last state)
■ lock disable, OFF
■ set external button short to value “1”
■ set external button short to value “0”
■ set external button long (manual mode)
to value “1”
■ set external button long (manual mode)
to value “0”
■ set object Day/Night to “Day” (for all
channels)
■ set object Day/Night to “Night” (for all
channels)
Setting the action to be executed
when a scene is called up.
Table 68: Settings – Scenes
The following table shows the associated communication objects:
No. Name/Object function Length Usage
94 Scene – Input 1 Byte Callupofapredenedscene.
Table 69: Communication objects – Scenes
