MDT technologies GmbH · Papiermühle 1 · 51766 Engelskirchen · Germany
Telephone: +49 (0) 2263 880 · knx@mdt.de · www.mdt-group.com
52 / 67
Technical Manual
Motion Detector/Automatic Switch 55/63 [SCN-BWM55/63(T)(06).x2]
State 07/2025 - Version 1.4
4.3.2.6 Basic function: Send value
Single-button function
With this function, different values of a datapoint type can be sent.
The following table shows the available settings:
ETS Text
Dynamic range
[Default value]
Comment
Datapoint type ■ 1 Byte DPT 5.005 Decimal factor (0...255)
■ 1 Byte DPT 5.001 Percent value (0...100%)
■ 1 Byte DPT 17.001 Scene Number
Setting the type of datapoint to
be sent.
Value /
Scene Number
any value
according to set datapoint type.
Setting the value / scene number
to be sent.
Table 62: Settings – Single-button function: Send value
The following table shows the associated communication objects:
No. Name/Object function Length Usage
131 Button left –
Send value, send percent value, ...
1 Byte Sends the value / the set scene number.
DPT depending on the parameter setting.
+5 Button right ...
Table 63: Communication objects – Single-button function: Send value
