45 / 67
Technical Manual
Motion Detector/Automatic Switch 55/63 [SCN-BWM55/63(T)(06).x2]
State 07/2025 - Version 1.4
4.3.1.3 Basic function: Switch
Two-button function
The following table shows the available settings:
ETS Text
Dynamic range
[Default value]
Comment
Button assignment
(left/right)
■ ON / OFF
■ OFF / ON
Denesthesendingbehaviourofthe
buttons.
Table 47: Settings – Two-button function: Switch
With the two-button function, the value (ON/OFF) can be assigned to the left and right button. Thus, the
leftorrightbuttonsendstheset,xedvalue.
■ Button assignment ON/OFF: The left button sends the value “ON”, the right button the value “OFF”.
■ Button assignment OFF/ON: The left button sends the value “OFF”, the right button the value “ON”.
The following table shows the associated communication objects:
No. Name/Object function Length Usage
131 Buttons left/right – Switch 1 Bit Switch function.
Table 48: Communication objects – Two-button function: Switch
